IQS620A Eval Kit 4

The IQS620A ProxFusion® IC is a multifunctional capacitance, Hall-effect & inductive sensor designed for applications where any or all of the technologies may be required. The IQS620A is an ulta-low power solution designed for short or long term activations through any of the sensing channels. The IQS620A is fully I2C compatible and can be configured to output main trigger events on GPIOs.


iqs624

EV-Kit Overview

  • Inductive sensing
  • Hall-effect seninsing
  • Capacitive sensing
  • Azoteq USB Dongle

Evaluation Modes

  • Connect to PC GUI via CT210/A or DS100 USB Dongle (included in the EV04 Kit)
    • Raw info displayed in GUI
  • Plug into Arduino Uno1 or ST Nucleo1
    • Sensor info displayed on 7-segment
    • Open source code for custom development
  • Embed the small module PCB (stamp) into custom design & interface to host MCU (Additional modules sold seperately as IQS620AEV01)



Applications:

  • Mobile electronics (phones/tablets)
  • SAR safety requirements for laptops, tablets and phones
  • Wearable devices
  • White goods and appliances
  • Human Interface Devices
  • Proximity activated backlighting
  • Applications with long-term activation
  • Aftermarket automotive2ARMmbedPartner contextual blue

Demo Software: Download

Datasheet: Download

ProxFusion® Pin-out Guide: Download



iqs620ev02






iqs620ev01 module

                     Stamp Module
